Описание
Размер: Налягане: 1/8 – 0.99 ~ 150 bar. 1/4 – 0.99 ~ 100 bar. 3/8 – 0.99 ~ 75 bar. 1/2 – 0.99 ~ 50 bar. 3/4 – 0.99 ~ 85 bar. 1″ – 0.99 ~ 80 bar.
| Код за поръчка: | A | B | L | D | CH | Наличност: |
|---|---|---|---|---|---|---|
| 301500005 | M5 | 4 | 6 | 8 | 2 | ✓ |
| 301500011 | M7x1 | 5 | 7.5 | 9.5 | 3 | ✓ |
| 301500006 | M8x1 | 5.4 | 8 | 12 | 4 | ✓ |
| 301500007 | M10x1 | 6 | 8.5 | 14 | 5 | ✓ |
| 301500001 | 1/8 | 6 | 8.5 | 14 | 5 | ✓ |
| 301500002 | 1/4 | 8 | 11 | 17 | 6 | ✓ |
| 301500008 | M12x1.25 | 8 | 11 | 15 | 6 | ✓ |
| 301500003 | 3/8 | 9 | 12.5 | 20 | 8 | ✓ |
| 301500004 | 1/2 | 10 | 13.5 | 25 | 10 | ✓ |
| 301500009 | 3/4 | 11.1 | 15.5 | 34 | 17 | ✓ |
| 301500010 | 1″ | 11.8 | 16 | 38 | 19 | ✓ |
